FRAMEAlloy Frame & Link Virtual 4 link kinematic VLK 29x2.6 / Boost 148x12mm UDH 160mm travel / Bosch SmartSystem / Integr. removable Battery 1.8" Headtube Central Kickstand Mount Integr. Cable
TRAVEL Front: 160mm / Rear: 160mm
FORK RockShox Domain Air 15x110mm QR axle / 1.8" Tapered Steerer Reb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
REAR SHOCK FOX Float EVOL eRIDE Trunnion 3 modes / Lockout-Trail-Descend DPS / Reb. Adj. Travel 160mm / 205x60mm
REMOTE SYSTEM SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 modes
DRIVE UNIT Bosch Performance CX EU: 25kmh / INT: 20mph
BATTERY PowerTube 750Wh
DISPLAY Bosch LED Remote & Kiox 300
CHARGER 4A Charger
REAR DERAILLEUR Shimano XT / 12 Speed
SHIFTERS Shimano SL-M6100
CRANKSET FSA CK-745 165mm / 34T
CHAIN GUIDE e*thirteen / e*spec Slider
CHAINRING FSA W0138+WB499 / 34T / Steel
CHAIN Shimano CN-M6100
CASSETTE Shimano CS-M6100 / 10-51T
BRAKES SRAM DB8 4 Piston Disc
ROTORSRAM Centerline CL Rotors 200mm F&R
HANDLEBAR Syncros Hixon 2.0 / Alloy 6061D.B. 12mm rise / 9° / 780mm Syncros Endurance lock-on grips H'STEMSyncros AM2.0 / 6061 Alloy 31.8mm / 4° / 1 1/8"
SEATPOST Syncros Duncan Dropper Post 2.5 Size S 125mm / Size M 150mm / Size L 170mm Size XL 200mm
SEAT Syncros Tofino 2.5 Regular
HEADSET Acros / 1.8" ZS66 OD74 / integr. Cable
HUB (FRONT) Shimano HB-MT410-B CL / 15x110mm
HUB (REAR) Shimano FH-MT410-B CL / Boost 12x148mm
SPOKES Stainless Black
RIMS Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
FRONT TIRE Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra
REAR TIRE Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra
LIGHTS Syncros integrated rear fender light Front Light Cable pre-installed
APPROX WEIGHTS IN KG 26.5 (with tubes)
